Carriages and Carriage Parts - Rated by the fork carriage lifting capacity, there are four sizings of hook type tine carriages. The hook type tine carriages have been standardized.
Class I carriages are rated for cargo up to 2000 lbs. The carriage bar spacing utilized for Class I is thirteen inches. Class II carriages are rated for cargo as much as 5,550 lbs. Their carriage bar spacing is 16 inches. Class III carriages are rated for cargo as much as 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for loads up to 15,500 lbs. The carriage bar spacing used for this capacity is 25 inches.
Pin mounted forks vary by the amount of offset between the fork and the blade eye. Some makers will vary the carriages for pin type blades. Carriage capacity will be established by the carriage pin size and by the blade size.
